Ejector Header
Ejector Header has two ox horn-like ear buttons (long ears and short ears), so people call this connector Ejector Header, which is a very simple internal wiring device to use.
Classification of Ejector Header: according to the spacing of PIN pins, Ejector Header with spacing of 1.27MM, Ejector Header with spacing of 2.0MM, Ejector Header with spacing of 2.54MM; According to the connection mode, it can be divided in o direct insrtion (180 degrees), bent insrtion (90 degrees) and SMT
Application of Ejector Header: Mainly used in computer equipment, industrial automation equipment, digital products, security equipment, electronic instruments, new energy products, medical devices and other fields
| Product Name: | Dongguan supplier Pitch 1.27mm 2.0mm 2.54mm 2.5mm straight, smt and right angle eject header connector with best price |
| Description: | Pitch: 1.27mm 2.54mm,2.0mm 1.0mm 5.08mm 3.0mm, 2.5mm Row Number :one or dual row Color: Black , Grey Orietional :straight, SMT, U type , right angle |
| Insulator Height for choice: | 4.9mm ,5.5mm ,5.7mm ,6.5mm ,7.3mm ,9.0mm ,9.4mm |
| Contact Material: | Brass |
| Contact Plating: | Gold (Au) or Tin (Sn) Plated over Nickel (Ni) |
| Insulator/Plastic Material: | PA6T ,PA9T ,LCP , PBT, PA66, PPS, PA115 accpet customer special requirement |
| Rating Current: | 1.00AMP |
| Contact Resistance: | 20mΩ Max |
| Insulating Resistance: | 1000 MΩ Min |
| Withstanding Voltage: | AC 500V/Minute |
| Temperture: | -40° C to +105° C |
| Material Flammability Rating: | UL94V-0 |
