2.54 Machined Pin Header， H=3.0 ，180°， PPS

Name: 2.54 Machined Pin Header， H=3.0 ，180°， PPS
SKU: YXCON-582
Availability: OutOfStock

2.54 Machined Pin Header

规格参数

产品货号：YXCON-582

Manufacturer 1.778/2.54/2.0/1.27 mm Pitch Round Pin Header 20 pin IC Socket

Product Description

Specification
Pitch	1mm,1.27mm,2mm,2.54mm,3.96mm,5.08,1.778mm
Material	PA6T,PA9T,LCP
Insrlator Material	Polyester(UL94V-0)
Contact Material	Brass
Contact Plating	AU OR SN OVER 40u" NI
Current Rating	1.5Amps
Withstanding Voltage	AC 500Vmin/Minute
Insulation Resistance	1000M Min
Operation Temperature	—40℃ to +150℃
Package	Bag packing,Tube packing,Tape&Reel packing
Application	Pcb board
Positions	1-40pin
Samples	Provided
Confirmation	Drawing will be provided before production
